Mini Outdoor Waterproof Terminal Box FTTH IP67 200N/cm Huawei SC

Product Categories
Shenzhen Unifiber Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Mini Outdoor Waterproof Terminal Box FTTH IP67 200N/cm Huawei SC

Brand Name : Unifiber or OEM

Model Number : 6 ports ftth terminal box huawei mini SC

Certification : ROHS

Place of Origin : China

MOQ : 10

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 500pcs/day

Delivery Time : 3~5 days

Packaging Details : Carton box

Product : 6 ports ftth terminal box huawei mini SC

No of ports : 4/6/8/12 ports

Connector : huawei mini SC

Waterproof Grade : IP67

Splitters : 1x4 or 1x8

Installation : Wall-mounting, aerial installation or holding pole installation.

Application : FTTH

Contact Now

FTTX Enclosure is a new economic fiber distributed solution for outdoor use. Compare traditional products, FTTX Enclosure is easy to operate and has high compatibility.It can be used for wall-mounting, aerial installation or holding pole installation, based on different situation. FTTX Enclosure not only used in FTTH field, but also used in FTTA or other harsh environment.

Product Features
1.Fiber optic splice box with utilize traditional field installation techniques for aerial, below ground and duct applications
2.100% optically tested to ensure quality performance assemblies at the factory
3.Available in single-mode and multimode styles to work with any common fiber type
4.Broad temperature range (-40 to+85°C) is ideal for indoor or outdoor applications
5.Drastically reduces field splicing with a predetermined loss at each waterproof tether access point
6.Provides moisture and dust protection for use in harsh industrial environments


Applications
1.Outdoor Fiber Optic Transmission
2.Optical System Access network
3.Storage area networking fiber channel
4.Data communication network, 5G tower
5.High density architectures
6.FTTA, FTTP, FTTX, WIMAX

Items Specifications
Dimensions LxWxH 365x137x90mm(Without cover) 375x142x120mm(With cover)
Ingress protection IP67
Temperature range -40 to + 80°C
Cable strength member Armoured or Non-armoured
Cable type Hybrid or non-hybrid
Round cable OD 5.0mm to 14mm
Flat cable dimension 4.6x8.9mm
Cable jacket material LSZH, PEorTPU
Bending Radius 20D
Cable crush resistance 200N/cm long term
Fire protection rating UL94-V0
Number of PLC 1 to 2pcs
Number of fusion protection sleeve 1 to 24pcs

Mini Outdoor Waterproof Terminal Box FTTH IP67 200N/cm Huawei SC
Mini Outdoor Waterproof Terminal Box FTTH IP67 200N/cm Huawei SC
Mini Outdoor Waterproof Terminal Box FTTH IP67 200N/cm Huawei SC
Mini Outdoor Waterproof Terminal Box FTTH IP67 200N/cm Huawei SC
